The LTspice circuit simulator is an educational and reference tool that is a member of the circuit simulators genre. According to the product description, it is a “high performance Spice III simulator, schematic capture and waveform viewer with enhancements and models for easing the simulation of switching regulators.” This is one of the most important selling factors it has. In place of LTspice, there are approximately a dozen alternative applications that are compatible with a range of operating systems. These platforms include of Android, Windows, Linux, and Mac computers, as well as web-based and online platforms. Circuit JS, which is not only free but also open source, is now the most appropriate choice because it can be used by anybody.
In terms of the characteristics they offer, QUCS, OpenModelica, Altium Designer, and Xcos are a few additional exceptional applications that compete favorably with LTspice. However, CAD Software and Electronic Design Automation Tools are additional viable alternatives to LTspice that should be considered as potential replacements. The most common alternative to LTspice is something called a Circuit Simulator. You can use any or all of these as criteria for the filter if you are looking for a particular feature of LTspice or if you want to reduce the number of options available to you.
Why Look for LTspice Alternatives?
Even though LTspice is a strong tool, there are a number of good reasons why you should consider looking into other options. It’s possible that you’re looking for a piece of software that provides a unique user interface, heightened functionality, or compatibility with specific operating systems. In addition, some engineers believe that the best way to meet the many requirements of simulation is to have a toolkit that has a wide variety of tools. In the sections that follow, we will discuss many aspects that should be taken into account while selecting an appropriate alternative for your circuit simulation attempts.
Best LTspice Alternatives
Circuit simulation software LTspice is used in electronics engineering. When searching for the top LTspice alternatives, it’s crucial to consider various options with unique features and capabilities. This article compares the main LTspice alternatives, detailing their merits and cons to help you choose.
KiCad
Features:
Due to the fact that it is open-source and has a wide range of capabilities, KiCad is recognized as being among the top LTspice alternatives. It provides a straightforward graphical user interface in addition to extensive PCB design tools and schematic capture capabilities. The fact that KiCad is compatible with Windows, macOS, and Linux makes it available to a wide variety of users. The design process is made easier by its extensive component library as well as its 3D visualization capabilities.
The Good
- Open-source and free
- Active user community
- 3D modeling for PCB visualization
The Bad
- Learning curve for beginners
- Limited advanced simulation options
QUCS
Features:
QUCS is one of the top contenders for the title of best alternative to LTspice. It provides an effective simulation platform that can be used by engineers of all expertise levels. QUCS allows accurate performance prediction thanks to its comprehensive set of tools for analyzing circuits. Its small design guarantees that system resources are used effectively, and its modular structure permits expansion without any noticeable break in continuity.
The Good
- Modular and expandable architecture
- Intuitive interface
- Support for SPICE models
The Bad
- Limited documentation
- Less active development compared to other tools
EveryCircuit
Features:
Through the use of interactive visualizations, EveryCircuit provides a novel way to the process of circuit simulation. Using this program, you will be able to construct and simulate circuits in real time, viewing the immediate effects of any changes you make. Because it can be used on a variety of platforms, including mobile devices, it is a fantastic option for engineers who are constantly on the move who are looking for a replacement for LTspice.
The Good
- Real-time interactive simulation
- User-friendly touch interface
- Mobile app for simulation on the go
The Bad
- Limited complexity for larger circuits
- Less comprehensive than traditional SPICE simulators
Solve Elec
Features:
The circuit analysis tool known as Solve Elec is designed to be simple to use and is appropriate for usage by both amateurs and experts. It provides a variety of simulation approaches, including as DC, AC, transient, and many more. Because it has a strong focus on simplicity and ease of use, Solve Elec is an appealing option for individuals who are looking for a straightforward yet effective alternative to LTspice.
The Good
- Simple and easy-to-use interface
- Suitable for educational purposes
- Diverse simulation techniques
The Bad
- Limited advanced features
- Lacks the depth of other professional tools
Proteus PCB Design
Features:
Proteus PCB Design provides users with a comprehensive set of tools for the design, simulation, and layout of printed circuit boards (PCBs). It integrates without any issues with the microcontroller simulation, making it one of the greatest alternatives to LTspice. This allows for the development of firmware alongside the circuit design. The accurate findings that it generates with its mixed-mode SPICE simulation can be used to analog, digital, and mixed-signal designs.
The Good
- Microcontroller simulation for firmware development
- Accurate mixed-mode simulation
- 3D visualization of PCB designs
The Bad
- High cost for full version
- Steeper learning curve for advanced features
Questions and Answers
Unfortunately, LTspice is not open source, does not support scripting, and does not let users to contribute their own code models to the program. NGSPICE is the way to go if you require these more advanced choices, however not many people do or care about these things.
LTSpice is a piece of software that excels at simulating electronic circuits and power electronics in the shortest amount of time possible. The word OrCAD refers to the entire software package that is used to assist in the design of printed circuit boards (PCBs). Within the OrCAD suite, the tool known as OrCAD capture is the one that enables users to ‘draw’ schematics.
