How to configure Wake on LAN feature in Windows 11

by Editorial Team
by Editorial Team

This tip is about the how to configure Wake on LAN feature in Windows 11. So read this free guide, How to configure Wake on LAN feature in Windows 11 step by step. If you have query related to same article you may contact us.

How to configure Wake on LAN feature in Windows 11 – Guide

Wake on LAN (WoL) is a networking feature that IT personnel have been accessing for years. WoL allows you to wake up from a distance up a remote computer via a “magical” data packet sent from another PC on your network.

The remote PC “listens” while in sleep or hibernation mode for the data packet. If the package is discovered, your PC wakes up up. This allows easier access to other Windows machines on a network, which means you don’t have to physically touch the other PC to wake it up. up and start using it.

If you want to enable Wake on LAN in Windows 11, here is what you need to do.

How to configure Wake On LAN in Windows 11

If you do not know how to wake up remotely up your Windows 11 PC with Wake On LAN, this article will help you. let’s go over how to enable and enable Wake On LAN feature, as how to configure and use to wake up remotely up your PC with Windows 11.

Enable Wake On LAN in Windows 11

First, you will need to enable Wake On LAN feature. You can enable Wake On LAN in the BIOS menu. To enable Wake On LAN on your Windows 11 PC, please follow the steps below:

  • Press Windows + I to open your PC settings.
  • In settings, go to the Windows Update section of the left sidebar.
  • Click on recovery in the Windows update section.
  • Here you will find advanced startups. Click restart now button next to the advanced boot option.
  • Your PC will restart. On the next screen that opens, select troubleshoot. Then select the advanced options and then select the UEFI firmware configuration option.
  • Select the Restart option and you will be taken to the BIOS.
  • In the BIOS, go to the power settings section.
  • Here you will find the Wake On LAN option; allow it.

    • If your PC does not have an Ethernet port, it will not support Wake On LAN. However, you can get a USB A 3.0 to RJ45 Gigabit Ethernet LAN adapter to give your PC Wake On LAN functionality.

    Wake On LAN Settings

    Next, you will need to configure Wake On LAN feature on your PC. To configure it, follow the steps below:

  • From the start menu, find the control panel and open it.
  • In the control panel, go to the network and internet section.
  • Now click on Network and Sharing Center and open it.
  • In the left sidebar, click Change adapter settings.
  • This will show all networks you have connected to.
  • Now select the active network adapter and right click on it. Click on the properties option.
  • In the properties of the network adapter, click the Configure button. button.
  • Now click on the advanced tab and select wake up up in the magic package.
  • Now on the right sidebar you will see a dropdown of values. From here, select enabled.
  • Then select wake up up in the magic pattern and enable it. Although this step is optional, you can do it.
  • Now select WOL and Shutdown Link Speed ​​and set the value to 10 MBps.
  • Then go to the power management tab.
  • Here, check Allow device to wake up up the computer, then select the Allow only one magic package to be activated checkbox up the computer case.
  • Once this is done, click on the OK button. button.

    • This is How to configure Wake On LAN feature. However, if you don’t want to use it, you can disable activation of the magic package as you previously enabled.

    Remote activation of PC with Windows 11

    Now that you’ve enabled Wake On LAN feature and set it up, let’s discuss How to wake up remotely up a Windows 10 PC. Follow the steps below to wake up remotely up the Windows 10 PC.

  • Download the NirSoft application and install it on your PC.
  • After installing the application on your PC, open it and click the Play button button to discover all devices on the network.
  • Now right click on the remote computer. Select the Enable selected computers option.
  • Now click on the yes button. That’s it, and you’ve completed the process.
  • Now the tool will start sending the magic package to the activation device.

    • Final note

    I hope you like the guide How to configure Wake on LAN feature in Windows 11. In case if you have any query regards this article you may ask us. Also, please share your love by sharing this article with your friends.
