How To Install Cacti monitoring Debian 11 Bullseye [2023]

Table of Contents

This tip is about the how To Install Cacti monitoring Debian 11 Bullseye. So read this free guide, How To Install Cacti monitoring Debian 11 Bullseye step by step. If you have query related to same article you may contact us.

How To Install Cacti monitoring Debian 11 Bullseye – Guide

The project behind the Debian Linux distribution has released Debian 11 stable, codenamed “Bullseye”. It is a version that has been working for two years, one month and nine days. Debian 11 follows the 2019 release of Debian 10 “buster”. As Steven J. Vaughan-Nichols of ZDNet noted, each Debian release is a big deal, with support coming from the user community rather than a company, as in SuSE Linux Enterprise (SLES). Debian is also the main operating system for other Linux distributions such as Canonical’s Ubuntu and Raspberry Pi OS.

Debian 11 will be supported for five years and is based on the Linux kernel 5.10 series, which was released in December with long-term support of two to six years. The Debian 11 release comes with several desktop environments including Gnome 3.38, KDE Plasma 5.20, LXDE 11, LXQt 0.16, MATE 1.24 and Xfce 4.16. Version 11 ‘bullseye’ is the first Debian release to provide a Linux kernel with support for the exFAT (Extended File Allocation Table) file system and is used by default to mount exFAT file systems. In this article, we show you how to install Cacti to monitor Debian 11 Bullseye.

How to install Cacti Debian 11 Bullseye Monitoring

requirements

To run this tutorial you need the following:

Debian server

DRR Tool

MySQL, PHP

Web server that supports PHP (Apache, Nginx, IIS, etc.)

Non-root user with sudo privileges

Internet connection

Update Debian Server 11

Before proceeding with this tutorial, first update your Debian 11 server to make sure that all packages available on your server up Until the present date. This will also regenerate the APT package manager cache.

sudo apt update && sudo apt upgrade

Install Apache for Cacti

To access the Cacti monitoring server web interface, you need to have the web server installed on Debian 11. Here, we have selected the popular open source Apache.

Start and activate the Apache web server.

sudo systemctl enable –now apache2

Install PHP and MariaDB

I’m using MySQL/MariaDB to store my data, but since Cacti Web UI is based on PHP, I installed this programming language on my system and I have some extensions needed for Cacti to work properly. need to add

first set up PHP.

sudo apt install php php-{mysql,curl,net-socket,gd,intl,pear,imap,memcache,pspell,tidy,xmlrpc,snmp,mbstring,gmp,json,xml,common,ldap}

sudo apt install libapache2-mod-php

Set PHP memory and runtime.

Edit the php.ini file.

sudo nano /etc/php/*/apache2/php.ini

press Ctrl + W and type – memory_limit

And change that value from 128 to 512M

Likewise, max_execution_time Change this value from 30 to 300.

search: date.timezone Set PHP timezone according to country.

date.timezone = Asia/Calcutta

hold Press to file Ctrl + O Then press input key and use Ctrl + X Exit.

Now also edit the PHP CLI file php.ini and set the timezone there as well.

sudo nano /etc/php/*/cli/php.ini

Set the fins and time zone again.

date.timezone = Asia/Calcutta

hold Press to file Ctrl + O Then press input key and use Ctrl + X Exit.

Install MariaDB

Once PHP is installed on your system, use the APT Package Manager to install the MySQL fork MariaDB server available for Debian 11 Bullseye from the official repository.

sudo apt install mariadb-server -y

Start and activate the database server.

sudo systemctl enable –now mariadb

To check your status:

sudo systemctl status mariadb

Create a MariaDB database for Cacti

sudo mysql -u root -p

CREATE DATABASE cacti DEFAULT CHARACTER SET utf8 COLLATE utf8_unicode_ci ;

GRANT ALL PRIVILEGES ON cacti.* TO ‘cacti_user’@’localhost’ IDENTIFIED BY ‘strongpassword’;

GRANT SELECT ON mysql.time_zone_name TO [email protected];

ALTER DATABASE cacti CHARACTER SET utf8mb4 COLLATE utf8mb4_unicode_ci;

FLUSH PRIVILEGES;

EXIT;

Configure MariaDB for Cacti.

sudo nano /etc/mysql/mariadb.conf.d/50-server.cnf

Copy and add the following line below – – [mariadb]

innodb_file_format=Barracuda

innodb_large_prefix=1

collation-server=utf8mb4_unicode_ci

server-charset=utf8mb4

innodb_doublewrite=OFF

max_heap_table_size=128M

tmp_table_size=128M

join_buffer_size=128M

innodb_buffer_pool_size=1G

innodb_flush_log_at_timeout=3

innodb_read_io_threads=32

innodb_write_io_threads=16

innodb_io_capacity=5000

innodb_io_capacity_max=10000

innodb_buffer_pool_instances=9

Also, add a # tag in front of these two available lines in the same file to make it unreadable.

#character-set-server = utf8mb4

#collation-server = utf8mb4_general_ci

Save the file. Ctrl + OHit Enter key and Ctrl + X Exit.

Then set the timezone in MySQL

sudo mysql_tzinfo_to_sql /usr/share/zoneinfo | mysql -u root -p mysql

Install SNMP and other tools for Cacti

You need some important tools for your Cacti monitoring system to work properly, such as SNMP and rrdtool. So this step installs them.

sudo apt install snmp snmpd rrdtool

To define up Cacti software on Debian 11.

Cacti can be installed using the APT package manager and the official Bullseye repository, but the versions available through Cacti are not up Until the present date.

therefore Duplicate the latest available on Github:

sudo apt install git

git clone -b 1.2.x

Move the duplicate Cacti file to your web directory.

sudo mv cacti /var/www/html

Use CactiSQL configuration A file to prepopulate in the database created for this purpose.

sudo mysql -u root cacti

Create a PHP configuration file for Cacti.

Well, composition The file already exists in the copied Cacti folder, so just rename it.

cd /var/www/html/cacti/include

cp config.php.dist config.php

Then edit config.php Add the details of the database you created for Cacti.

Database value changes – database name, username, when password.

Save the file Ctrl + OHit input Press the key to exit. Ctrl + x.

Give the Apache user permission to access the Cacti folder in the web root directory.

sudo chown -R www-data:www-data /var/www/html/cacti

Create a CactiSystemd Service

To run the Cacti Polar service in the background, create a Cacti system service using the specified command.

sudo nano /etc/systemd/system/cactid.service

Add the following line.

Unit

Description=Cacti Daemon Main Search Service

After=network.destination

Service

Type = fork

User=www-data

Group=www-data

EnvironmentFile=/etc/default/cactid

ExecStart=/var/www/html/cacti/cactid.php

restart=always

RestartSec=5s

Install

WantedBy=multi-user.destination

Save the file Ctrl + Opush input Press the key to exit Ctrl + X..

Create an environment file.

sudo touch /etc/default/cactid

Start and activate the Cacti service

sudo systemctl daemon-reload

sudo systemctl enable cactid

sudo systemctl restart cactid

Login to Cacti Monitoring on Debian 11.

After the installation is complete, access your system browser and enter the IP address of the server where you installed the Cacti Monitoring software.

Specify the following location in your browser:

http://server-IP-address/cacti/

Start installing Cacti Web

In the first step, the installation wizard will ensure that you have everything you need for Cacti to work. If any of the requirements are not met, it will be reflected on the screen. And we have to do the same. That way, only we can move forward.

In the next step, the system checks that all the permissions that Cacti needs to access the file are set.

By default, “New Main Server” is selected. This is because it is the initial server that monitors other devices.

Finally install Cacti panel on Debian 11 Bullseye

Final note

I hope you like the guide How To Install Cacti monitoring Debian 11 Bullseye. In case if you have any query regards this article you may ask us. Also, please share your love by sharing this article with your friends.
